0.3MP Fixed Focus IR Filter DVP Camera Module With Omnivision OV7740 CMOS Sensor

0.3MP Fixed Focus IR Filter DVP Camera Module With Omnivision OV7740 CMOS Sensor

제품 상세 정보:

원래 장소: 중국 광둥
브랜드 이름: sinoseen
모델 번호: SNS-DualOV9732-M1.0

결제 및 배송 조건:

최소 주문 수량: 5
최고의 가격 접촉

상세 정보
렌즈 보기: 60° 비디오 압축 형식: H.264
보관 온도: 85' Ｃ에 대한 -30' Ｃ 작동 온도: 0°C ~ 60°C
이미지 센서: OV7740 직렬 인터페이스: DVP
유효 픽셀: 640 x 480 픽셀 크기: 4.2μm x 4.2μm
비디오 출력: 원시 바이어10bit/8bit 활성 배열 크기: 640×480 @ 60fps, 320×240 @ 120fps
센서 크기: 1/5" TV 왜곡: <1%
작동 전압: AVDD:3.0~3.6V DOVDD:1.7~3.6V DVDD:1.7~1.9V 보관 온도 범위: -20~70C
USB 케이블 길이: 채무 불이행
강조하다:

0.3MP fixed focus camera module

,

IR filter DVP camera module

,

Omnivision OV7740 CMOS sensor

제품 설명

0.3MP Fixed Focus IR Filter DVP Camera Module
This professional camera module features the Omnivision OV7740 CMOS sensor with DVP interface, delivering reliable imaging performance for industrial applications.
Key Features
  • 0.3MP resolution with 640×480 effective pixels
  • Omnivision OV7740 CMOS sensor technology
  • DVP interface with Raw Bayer 10bit/8bit video output
  • Lens compensation and automatic white balance functions
  • High frame rates: 60fps at 640×480, 120fps at 320×240
  • Compact 1/5" sensor size with 4.2μm pixel size
  • Support for AEC, AEB, and AGC functions
  • Customizable lens options and dimensions
Technical Specifications
ParameterSpecification
Module NumberSNS-FPC7740-V1
Pixel Size4.2μm × 4.2μm
Effective Pixels640×480
Video OutputRaw Bayer 10bit/8bit
Active Array Size640×480 @ 60fps, 320×240 @ 120fps
Image Sensor1/5" Omnivision OV7740
Lens ViewFOV60° (optional), F/N (optional)
TV Distortion<1%
Operating VoltageAVDD: 3.0~3.6V, DOVDD: 1.7~3.6V, DVDD: 1.7~1.9V
Operating Temperature0～60℃
Storage Temperature-20～70℃
DimensionsCustomizable
Product Images
0.3MP DVP Camera Module front view 0.3MP DVP Camera Module side view 0.3MP DVP Camera Module technical details
Customization Services
We specialize in OEM/ODM customized CMOS image processing solutions, offering complete design, development, manufacturing, and after-sales services. Our expertise includes USB, MIPI, and DVP camera modules for various applications.
Application Areas
Machine vision, intelligent systems, security solutions, IoT devices, iris recognition, face recognition, VR applications, smart home solutions, UAV/drone cameras, mobile phone modules, and professional imaging systems.
Camera module application areas diagram
Customization Process
We work closely with clients to determine optimal camera solutions based on application requirements, structural constraints, image quality needs, lighting conditions, and budget considerations.
Camera module customization process flowchart
Quality Assurance
Shenzhen Sinoseen Technology provides competitive pricing and quality assurance with comprehensive certifications and testing procedures.
Company quality certifications
Contact us to discuss your specific camera module requirements and receive customized solutions tailored to your application needs.
