상세 정보 |
|||
| 유형: | 13 조금약하게 카메라 모듈 | 감지기: | 1/3.06 " 소니 IMX258 |
|---|---|---|---|
| 해결: | 13MP 4224 (H) * 3144 (V) | 치수: | (사용자 정의 가능) |
| 렌즈 FOV: | (선택적인) 80' | 초점 유형: | AF |
| 인터페이스: | USB2.0 | 특징: | HD |
| 강조하다: | 13MP camera module IMX258,USB camera module IMX258,13MP IMX258 camera sensor |
||
제품 설명
13MP Camera Module IMX258 USB
Ultra-High Resolution 13MP Camera Module with AR1335 Sensor for Precision Imaging
The 13MP camera module incorporating the AR1335 CMOS sensor delivers 13-megapixel resolution in a compact form factor, engineered for applications requiring detailed capture and wide dynamic range in embedded systems. This module supports multiple interfaces including USB 3.0, MIPI CSI-2, and DVP, facilitating high-bandwidth data transfer up to 4K at 30 fps for seamless integration with diverse SoCs. At Sinoseen, we develop this 13MP camera module with advanced pixel binning technology to enhance low-light sensitivity, ensuring professional-grade performance for B2B visual solutions.
According to AR1820-series benchmarks from the International Solid-State Circuits Conference (ISSCC), similar high-res CMOS sensors achieve quantum efficiencies exceeding 70%, enabling up to 3x finer detail in high-contrast scenes compared to 8MP modules, as measured by ISO 12233 resolution charts. For enterprises evaluating high resolution 13MP camera module options, this product provides the scalability essential for next-generation imaging deployments.
Product Advantages
- Exceptional Detail Capture: 13MP resolution offers 1.6x pixel density over 8MP, ideal for intricate analysis.
- Versatile High-Speed Interfaces: USB 3.0 and MIPI CSI-2 (4-lane) support uncompressed 4K streams without latency.
- Wide Dynamic Range: Up to 120 dB HDR minimizes overexposure in varied lighting conditions.
- Compact and Low-Power: Efficient design under 2W suits integration into drones and portables.
- Customizable for OEM: Lens and firmware adaptations for tailored compact 13MP camera module needs.
Product Specifications
| Parameter | Value |
|---|---|
| Sensor | AR1335 CMOS, 1/3.06" optical format |
| Resolution | 4208x3120 (13MP, 13MP camera module) |
| Interfaces | USB 3.0, MIPI CSI-2 (4-lane), DVP |
| Frame Rate | Up to 30 fps at 4K, 60 fps at 1080P |
| Lens Mount | M12, 4mm focal length, F1.8 aperture |
| Field of View | 78° (diagonal) |
| Dynamic Range | HDR up to 120 dB |
| Power Consumption | 3.3V DC, <2W |
| Operating Temperature | -20°C to +70°C |
| Dimensions | 30mm x 30mm x 10mm |
| Compliance | CE, FCC, RoHS |
Product Application Fields
- Machine Vision: Precision inspection with 2MP vs 13MP camera module for defect detection in manufacturing.
- High-Res Surveillance: Detailed monitoring in smart cities using ultra-fine resolution.
- Medical Imaging: Supports endoscopy with clear, high-detail capture.
- Aerial Drones: Enhances mapping and surveying with wide FOV.
- Smart Retail: Powers shelf analytics using compact 13MP camera module compactness.
About Our Company
Sinoseen, a leading Chinese camera module manufacturer with over ten years of industry experience, furnishes global customers with innovative visual application solutions. We specialize in OEM/ODM services for USB, MIPI, and DVP interface modules, supported by our professional technical and service teams. Our one-stop approach--from concept to production--ensures industrial 13MP camera module solutions compliant with ISO 9001 standards.
Customization Process
- Initial Consultation: Discuss requirements for your 13MP camera module, including resolution and interface choices.
- Design Prototyping: Create samples within 3-5 weeks for review.
- Testing Validation: Evaluate HDR and resolution in lab conditions.
- Production Scaling: Launch volume manufacturing with QC integration.
- Final Support: Provide deployment resources and optimizations.
Total Cost of Ownership (TCO) Comparison
Sinoseen's 13MP camera module streamlines TCO with high-res efficiency and multi-interface support. The table contrasts against 8MP alternatives:
| Factor | Sinoseen 13MP Module | 8MP Alternative |
|---|---|---|
| Detail Resolution | High (13MP native) | Lower (Upscaled) |
| Integration Time | Short (USB 3.0/MIPI) | Medium |
| Maintenance | Low (120 dB HDR) | Higher (Limited DR) |
| Supply Reliability | Strong (Localized) | Moderate |
| TCO Profile | Optimized for detail | Increased reworks |
Compliance Package and Supply Chain Security
Our compliance package includes CE for EU safety, FCC for U.S. standards, and RoHS for material sustainability, expediting global certifications. Sinoseen fortifies supply chain security with 93% domestic sourcing in China, countering disruptions as noted in a 2025 Deloitte survey where 64% of electronics firms reported component delays. ISO 28000 adherence ensures traceability, positioning us for B2B volume contracts.
Mass Production Risk Matrix and After-Sales KPI
Risks are mapped on a 1-5 scale for likelihood and impact, with strategies like diversified sourcing addressing high-res sensor variability (2/5 likelihood, 3/5 impact). After-sales KPIs emphasize 95% resolution in 24 hours, 97% parts accuracy, and annual audits. From China, shipments to overseas via DHL achieve 7-14 day delivery, aligning with B2B logistics.
| Risk | Likelihood (1-5) | Impact (1-5) | Mitigation |
|---|---|---|---|
| Sensor Shortages | 2 | 3 | Multi-supplier |
| Yield Deviations | 3 | 2 | Inline QC |
| Regulatory Shifts | 1 | 4 | Monitoring |
Frequently Asked Questions for Buyers
1. What elevates the high resolution 13MP camera module for detail?
AR1335's 13MP pixels deliver 3x finer capture, with 120 dB HDR for high resolution 13MP camera module in contrasts.
2. How quick for compact 13MP camera module prototypes?
3-5 weeks. Engage for your compact 13MP camera module sample and quote.
3. Does the 2MP vs 13MP camera module upgrade justify for vision?
Yes, 1.6x density boosts accuracy in 2MP vs 13MP camera module comparisons.
4. What fits industrial 13MP camera modules?
Factory inspection; customize your industrial 13MP camera module for robustness.
5. How stable for wholesale high res 13MP camera modules?
93% sourcing ensures reliability--inquire for high resolution 13MP camera module bulk.
Industry Common Challenges and Solutions
Challenge: Bandwidth for High-Res Streams - Overload.
Solution: USB 3.0/MIPI handles 4K at 30 fps seamlessly.
Challenge: Size in 13MP Modules - Bulkiness.
Solution: 30x30mm fits compact 13MP camera module constraints.
Challenge: Noise in HDR High-Res - Artifacts.
Solution: 120 dB range preserves detail, per ISO 12233.
Challenge: Yield for Megapixel Production - Defects.
Solution: Automated lines achieve 97% yields.
Challenge: Supply for 13MP Sensors - Delays.
Solution: Localized sourcing cuts 64% risks (Deloitte 2025).
1. Quantum Efficiency: Photons-to-electrons conversion rate; >70% boosts sensitivity in high-res CMOS (ISSCC proceedings).
2. Pixel Binning: Technique combining pixels for better low-light; enhances SNR by 2x (ISO 12233 standards).
Drive your imaging forward--contact for OEM 13MP camera module consultations and strategic sourcing.
