IMX317 USB Camera Module 8MP 4K 30FPS Fixed Focus

IMX317 USB Camera Module 8MP 4K 30FPS Fixed Focus

제품 상세 정보:

Place of Origin: Shenzhen,China
브랜드 이름: Sinoseen
인증: RoHS
Model Number: SNS-DZ1009-V1.0

결제 및 배송 조건:

Minimum Order Quantity: 3
가격: 협상 가능
Packaging Details: Tray+Anti-static bag in carton box
Delivery Time: 2-3weeks
Payment Terms: T/T
Supply Ability: 500000 pieces/month
최고의 가격 접촉

상세 정보

Type: USB Camera Module Sensor: IMX317 1/2.5 inch
Resolution: 8MP 3840*2160 Dimensions: Customizable
Frame Rate: 30FPS Lens FOV: 82°(optional)
Interface: USB

제품 설명

Sinoseen IMX317 CMOS Sensor Camera Module - The Ultimate Choice for 4K Clarity and Seamless Integration with USB Interface
Product Attributes
Type USB Camera Module
Sensor IMX317 1/2.5 inch
Resolution 8MP 3840*2160
Dimensions Customizable
Frame Rate 30FPS
Lens FOV 82° (optional)
Interface USB
Product Description

Still searching for a camera that offers both 4K clarity and high flexibility across various application scenarios? The Sinoseen SNS-DZ1009-V1.0 Camera Module provides ultimate 4K clarity, making it your ideal versatile solution for multiple scenarios.

It features an IMX317 CMOS sensor, supporting 3840 x 2160 4K Ultra HD video with a smooth output of 30 frames per second. This completely addresses the shortcomings of traditional modules in detail capture and motion fluidity. Its fixed-focus design further simplifies integration, enabling reliably clear imaging without complex focusing, effectively reducing design and maintenance costs.

This module's USB interface offers unparalleled plug-and-play convenience, allowing seamless integration into digital cameras, dash cams, sports cameras, security surveillance systems, and even industrial equipment. Whether you need to record high-quality videos for outdoor activities, provide detailed security footage for vehicles, or deliver precise visual feedback for production lines, the SNS-DZ1009-V1.0 can meet your needs.

Specifications
Module SNS-DZ1009-V1.0
Sensor IMX317 CMOS
Image sensor size 1/2.5 inch
Pixel 8MP
Most effective pixels 3840*2160
Pixel Size 1.62um*1.62um
Frame rate 30fps
Focus type Fixed focus
Output interface USB2.0
Video output MJPG/YUV
Output formats RAW Bayer 10bits
Max S/N ratio TBD
Dynamic TBD
Storage temperature -20°C to 70°C
Operating temperature 0°C to 60°C
Support OS WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC
Product Images
